#TDI MRM100H Micro Ruler – .220″W/5mm Range


High Precision Micro Rulers

Calibrated to .1mm (5mm Range)

Width of Ruler: .220″

Photo etched scale.  Very accurate for general under microscope measuring.  Not NIST calibrated.

  • These unique micro rulers may be used directly under a microscope or magnifier.
  • Speedy measuring of small parts, grooves, slots, line widths, holes, chamfers, etc.
  • Precision fabricated from stainless steel.
  • Micro rulers are spot-welded to bendable shank (plated metal – magnetic)
  • Micro ruler blades are non-magnetic stainless steel.
  • Hexagonal shaped handles prevent these micro rulers from rolling off your workstation.
  • Handles are non-magnetic, gold anodized aluminum.
  • Each micro ruler is individually packaged in a plastic box.
  • Overall length: 83mm (3.25″)
